Smart Separation for
Your Workflow
Exceed your limits with the Centrifuge CP-NX Series
Ultracentrifugation can be challenging, thus user-friendly
and safe operation is crucial. Therefore, the flagship of
our ultracentrifuge portfolio has been designed to make
ultracentrifugation as safe and convenient as possible.
With speeds of up to 803,000 × g (100,000 rpm)*1, it is the
optimal solution for the separation of nucleic acids, proteins,
protein complexes, vesicles, and viruses, just to name a few.
*1 The CP-NX models are available with max. speeds of 100,000 rpm. For details see last page.
*2 Except Rotor P21A2
Combine Safety and Efficiency With Simple Operation
Automatic rotor detection and
Rotor Life Management System (RLM)
Convenient recognition of rotors and exact
digital tracking of rotor run times eliminate
the need for manual logs. In addition,
the precise tracking of rotor speeds and
run times maximizes the lifetime of the rotor
and ensures long-lasting performance.
Visual sample balance
Balance samples by eye up to 5 mm
height difference – no scale required!*2
The powerful non-contact imbalance system always
monitors the vibration of rotor and drive shaft.
In case of unusual vibrations, the system stops the run.
Self-locking rotor system
Rotor locks by centrifugal force.
Simply place the rotor on the
drive shaft… that’s it!
Intuitive touchscreen
Offers documentation functions and user
management to support GxP compliance
Fast turn-on time
Ready to go in just 6 seconds- no waiting
time anymore!
Front-mounted
LED status bar
View operating
status at-a-glance
from distance.
Tubes for large sample volumes.
Available in different materials and
wall thicknesses to match your
analytical
needs – from optical clarity
in PET tubes to corrosion-resistant,
stainless-steel tubes.
Heat-sealing tubes for handling
and protecting precious samples.
An additional tube sealer and rack
is available for heat sealing tubes.
Bottles that are easy to open and
close. Available with screw-style cap
enclosures for high-speed pelleting.
Easy Choice: A Selection of Comprehensive Rotors
and Consumables
Rotor Capacity range Max. speed K-factor Included consumable Order number
Fixed Angle Rotors: high-speed, 25-45° angle rotors are ideal for pelleting applications
P21A2 6 × 230 mL 71,000 × g 486 6 × 230PP Bottle 5720 211 205
P45AT 6 × 94 mL 235,000 × g 130 5720 211 109
P50A3 24 × 1.5 mL 252,000 × g 33 300 × 1.5 mL MicroTube (C) 5720 211 108
P50AT2 12 × 3 mL – 12 × 40 mL 303,000 × g 70 5720 211 107
P70AT 8 × 3 mL – 8 × 40 mL 505,000 × g 44 5720 211 105
P70AT2 12 × 0.9 mL – 12 × 12 ml 452,000 × g 36 5720 211 104
P80AT 8 × 0.9 mL – 8 × 12 mL 615,000 × g 27 5720 211 103
P90AT 8 × 0.9 mL – 8 × 12 mL 700,000 × g 25 5720 211 102
P100AT2 8 × 4 mL – 8 × 6.5 mL 803,000 × g 18 5720 211 101
Swing Bucket Rotors: allow maximum sedimentation and are ideal for density gradient applications
P28S 6 × 33 mL – 6 × 40 mL 141,000 × g 252 100 × 40PP tube 5720 214 005
P32ST 6 × 33 mL – 6 × 40 mL 180,000 × g 198 100 × 40PP tube 5720 214 003
P40ST 6 × 0.9 mL – 6 × 13 mL 284,000 × g 139 100 × 13PP tube 5720 214 002
P55ST2 6 × 0.9 mL – 6 × 5 mL 366,000 × g 50 100 × 5PP tube 5720 214 001
Vertical Angle Rotors: allow short sedimentation distances and provider fast separations
P100VT 8 × 5 mL 700,000 × g 6 5720 213 001
Discover the now complete centrifugation range
from Eppendorf
www.eppendorf.com/your-centrifuge-solution
Start Separation at Ease
Apple® ist a registered trademark of Apple Inc. USA. · Google Play® is a registered trademark of Google Inc., USA.
Eppendorf®, the Eppendorf Brand Design and the epServices® logo are registered trademarks of Eppendorf SE, Germany.
Himac® is a registered trademark of Eppendorf Himac Technologies Co., Ltd., Japan.
Order No. EN3/PDF/1123/MCP · All rights reserved, including graphics and images. Copyright © 2023 by Eppendorf SE.
Your local distributor: www.eppendorf.com/contact
Eppendorf SE · Barkhausenweg 1 · 22339 Hamburg · Germany
eppendorf@eppendorf.com · www.eppendorf.com
www.eppendorf.com
Ultracentrifuges
Model Centrifuge CP100NX Centrifuge CP90NX Centrifuge CP80NX
Max. RPM 100,000 90,000 80,000
Max. RCF (× g) 803,000 700,000 615,000
Order No. 230 V Variant, no plug*3 5720 110 012 5720 109 012 5720 108 012
Order No. 208 V Variant, NEMA 6-30P plug 5720 110 013 5720 109 013 5720 108 013
Order No. 220 V Variant, no plug*3 5720 110 011 5720 109 011 5720 108 011
Order No. 200 V Variant, no plug*3 5720 110 010 5720 109 010 5720 100 810
Power consumption 3,300 W
Nominal volume Up tp 6 × 230 mL
Noise level <51 dB(A)
Acceleration / breaking ramps 10 / 11 (including coasting)
Display Touch-sensitive color LCD panel (6.5 in)
Timer from 1 min to 999 hours 59 min (with 1 min increments) with HOLD function
Power supply Single phase: AC 200 – 220 V ±10%, 50 / 60 Hz ,20 A,
Single phase: AC 230 – 240 V ±10%, 50 / 60 Hz ,16 A,
Single phase: AC 208 V ±10%, 50 / 60 Hz, 20 A
Maximum number of log files Up to 5,120 logs
Footprint (W × D) 790 × 690 mm / 31.1 × 27.2 in
Height 925 mm / 36.4 in
Weight (w/o) accessories 390 kg / 859.8 lbs
Refrigeration Thermo-module cooling system (HFC-free)
Temperature control range from 0ºC to 40ºC
Vaccuum system Oil rotary vacuum pump and oil diffusion pump
Safety functions Interlock door, overspeed detection, overload detection, imbalance detection, over-temperature
detection, vacuum detection, power failure detection, automatic rotor lifetime management
system, micro-filter (optional)
Connectivity USB, LAN
Optional software »Himac ASSIST« for planning centrifugation experiments
»Himac View« from Apple® store or Google Play® for remote control
»Himac Log Manager« for logging device information
*3 For correct installation contact our technical experts.
We are committed to providing reliable services and tools at your
location. This includes a comprehensive range of carefully designed
service solutions performed by our dedicated manufacturer-trained
and certified Technical Service teams worldwide.
www.eppendorf.com/centrifuge-service
Ensure Top System Performance: Eppendorf Services
Technical Specifications
